DipTrace is quality Schematic Capture and PCB Design software that offers everything to create simple or complex multi-layer boards from schematic to manufacturing files.

Schematic Capture


Advanced schematic tool with the support of multi-sheet and multi-level hierarchical design that allows the engineer to connect pins visually, without wires, using net ports, buses, or logically. Electrical Rule Check and hierarchy verification work from the earliest stages of design till the work is done. Schematic supports import and export of different EDA/CAD and netlist formats.

PCB Layout


High-quality board-level design tool that features smart placement and routing tools, shape-based autorouter, copying hierarchical blocks, smart project structure, and verification features that ensure accuracy even for the most complex projects with high-speed signals. Real-time DRC allows for fixing errors on the fly and increases quality all the way to the project completion. Import and export various EDA, CAD, netlist, and manufacturing formats.

Library Creation


Cross-module library management system with component and pattern editors and direct import from outside the DipTrace design environment. Component and Pattern editors support smart library structure and fast creation of components and patterns with integrated templates. Bulk pin naming, pad numbering, and editing features allow the designer to build multi-part complex components and patterns with hundreds of pins faster than ever before.

3D Modeling


Works as a part of the PCB Layout and Pattern Editor. The 3D module allows the designer to preview the board with installed components on any design stage, rotate and move it in real-time with hardware acceleration. Board 3D model can be exported to mechanical CAD (STEP, VRML). DipTrace imports 3DS, VRML, STEP, and IGES files as 3D models. 7500+ models are supplied free of charge.
